TECHNICAL SPECIFICATIONS:
Oscillation Mode: PLL Phase Locked Loop Frequency SynthesisRF Stability: ±0.005% (-10~50°C)
Carrier Frequency Range: UHF 500~950MHz (Standard: 640~690MHz)Bandwidth: 50MHz
Receiving Method: Dual Conversion Receiver
Sensitivity: S/N>80dB when input is 6dBV with an offset of 40KHzMaximum Offset: ±68KHz with volume expansion
Overall S/N Ratio: >105dB(A)
Overall Distortion (TH.D.): <0.5% @ 1KHz
Overall Frequency Response: 50Hz~18KHz +3dB
Maximum Output Voltage: Balanced: +10dB (2.5V)/600Q; Unbalanced: +4dB (1.25V)/5KQSilent Control Mode: Dual silent control using audio code and RF siqnal strengthDC Power Supply: 12V/500mA
Package Dimensions: 600mm (Length)x 320mm (Width) x 80mm (Height)
