TECHNICAL SPECIFICATIONS:
Stereo power16Q: Stereo power output 300W
Stereo power8Q: Stereo power output 600W
Stereo power4Q: Stereo power output 1200WStereo power2Q: Stereo power output 1500WFrequency response: Frequency response (+0/-0.31W/8) 20Hz-20KHz, 3dB @ 100KHzTotal harmonic distortion: THD+N (20Hz -20KHz)<0.03%DA MPING Factor: 400
S/NRatio:>70dB
Input Sensitivity: 0.775V/1V/1.4V
Protection: 0verheat, Short-circuits, DC, Limit and Soft-Start, 0utput Relay-Zero CurrentSwitch, Intellectual ClipLimiter
Dimensions(LxWxH):L510mm x W485mm x H89mm
1. The 01G series amplifiers cover a power range of 300W-3400W from 16Q to 22
2. The LG series can handle stereo loads of 20 and bridged loads of 42, making it suitable for driving lineararray loudspeaker systems
3. The OLG series is suitable for large-scale mobile performances, band performances, DlSC0, and other
occasions
4. Modes: bridged mode, parallel mode, stereo mode
5. Power-on protection against voltage surge, gradual increase in volume at startup, soft start at power-on,
peak limiter
6. Temperature protection, short-circuit protection, overcurrent protection, overload protection, voltage limitprotection, direct current detection protection
7. Zero static noise
