Note: Deflections reported in the tables on the left are the maximum expected for full loading ( indoor only). All loads are based on 8′(2.44m) sections.other section lengths are available. Load tables are reprinted from engineering reports developed by Herman Huang & TUV Germany. Structural engineers,and apply to truss fabricated after February 2010.

Span feet(meters)	load kgs/ft	load lbs(kgs)	Max Defl mm	load lbs(kgs)	Max Defl mm	load lbs(kgs)	Max Defl mm	load lbs(kgs)	Max Defl mm
10(3.05)	446	4460 2023	3.6	2231 1012	2.8	1673 759	3.6	1116 506	3.3
20(6.09)	106	2120 962	13.7	1063 482	11.2	797 362	14.2	531 241	13.2
30(9.14)	43	1290 585	31	650 295	25.7	487 221	31.8	325 147	29.7
40(12.2)	21	840 381	54.9	426 193	47	319 145	56.1	213 97	53.3
